Dahua HTI-UC300 Web Camera, 1/2.9" CMOS, 2M Pixel Sensor Type, 85° Horizontal FOV, MJPEG/YUV Compression, Auto Exposure, 2D Digital Noise Reduction, 3.0mm Focal Length, Black | HTI-UC300
()
Size
Check
serviceability at your Pincode
HTI-UC3002MP Web Camera Key Features
1080P FHD Image SensorSupport multiple resolutions like 1080p (Full HD) @ 30/25 fps and 720p (HD) @30/25 fps to best support the video quality, and it's horizontal field of view can be up to 85°.
Unified Interface USB 2.0Support plug and play, provides power supply, video and audio functions.
Built-in MicrophoneOmnidirectional built-in microphone with 3 meters pickup distance, provides business-class audio performance.
Low Light PerformanceThe ultra-high SNR CMOS image sensor can effectively reduce image noise at low light conditions. Meanwhile, 2D noise reduction algorithms are employed to sharply reduce image noise. So the images keep clean and clear even under ultra-low light conditions.
Easy InstallationFree to mount the camera on top of screen or on desktop
Specifications
Sensor Type
1/2.9" CMOS, 2M pixel
Video Format
MJPEG
1080p@30fps/25fps/20fps/15fps/10fps/5fps, 720p@30fps/25fps/20fps/15fps/10fps/5fps, 480P@30fps/25fps/20fps/15fps/10fps/5fps, 320x240p@30fps/25fps/20fps/15fps/10fps/5fps
YUV
1080p@5fps, 720p@10fps/5fps, 480P@30fps/25fps/20fps/15fps/10fps/5fps, 320x240p@30fps/25fps/20fps/15fps/10fps/5fps
Compression
MJPEG/YUV
UVC Protocol
Support UVC protocol and driver-free adaptation to Windows, Linux, Mac OS, Android and other operating systems
Horizontal Field of View
85°
Delay
Image lag ? 170ms
Exposure
Auto
Shutter Speed
1/30s ~ 1/10000s
Digital Noise Reduction
2D Digital Noise Reduction
SNR
?50dB
White Balance
Support
Focal Length
3.0 mm ± 5% (0.12"± 5%)
Lens Interface
M8
Distortion
-2.11%
Close-up Distance
0.2m (0.65ft)
Microphone
Position
Built-in
Pickup Distance
Omnidirectional, Pickup Distance Up to 3m
Audio Coding Format
16KHZ/48KHZ PCM
General
Video Interface
1 * USB2.0
Working Status Indicator
Green
Power Supply
USB 5V
Color
Black
Max. Input Current
400mA
Max. Power Consumption
2W
Dimension
109.5mm*66mm*52.7mm (4.31"*2.59"*2.07")
Net Weight
111g (0.24lb)
Box Dimension
115mm*65mm*75mm (4.52"*2.55"*2.95")
Box Weight (with 1 product)
143g (0.31lb)
Protective Box Dimension
407mm*369mm*361mm (16.02"*14.52"*14.21")
Packaging Method
75 in 1
Operating Temperature
0°~+40° (+32?~+104?)
Operating Humidity
< 95% (Noncondensing)
Continuous Operating Time
? 72h of continuous normal operation
Storage Temperature
-20°~+60° (-4?~+140?)
Storage Humidity
< 95% (Noncondensing)
System Requirements
OS
Windows® 7 , Windows 8.1, Windows 10 or Higher
macOS™ 10.10 or Higher
Google™ Chromebook™ Version 29.0.1547.70 or Higher
Linux (UVC Protocol Required)
Certifications
Certifications
CE(EMC): EN 55032:2015+A11:2020, Class B; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE(LVD): EN 62368-1:2014+A11:2017; IEC 62368-1:2014 (Second Edition)
FCC: 47 CFR FCC Part15, Subpart B, Class B
Sensor Type
1/2.9" CMOS, 2M pixel
Video Format
MJPEG
1080p@30fps/25fps/20fps/15fps/10fps/5fps, 720p@30fps/25fps/20fps/15fps/10fps/5fps, 480P@30fps/25fps/20fps/15fps/10fps/5fps, 320x240p@30fps/25fps/20fps/15fps/10fps/5fps
YUV
1080p@5fps, 720p@10fps/5fps, 480P@30fps/25fps/20fps/15fps/10fps/5fps, 320x240p@30fps/25fps/20fps/15fps/10fps/5fps
Compression
MJPEG/YUV
UVC Protocol
Support UVC protocol and driver-free adaptation to Windows, Linux, Mac OS, Android and other operating systems
Horizontal Field of View
85°
Delay
Image lag ? 170ms
Exposure
Auto
Shutter Speed
1/30s ~ 1/10000s
Digital Noise Reduction
2D Digital Noise Reduction
SNR
?50dB
White Balance
Support
Focal Length
3.0 mm ± 5% (0.12"± 5%)
Lens Interface
M8
Distortion
-2.11%
Close-up Distance
0.2m (0.65ft)
Microphone
Position
Built-in
Pickup Distance
Omnidirectional, Pickup Distance Up to 3m
Audio Coding Format
16KHZ/48KHZ PCM
General
Video Interface
1 * USB2.0
Working Status Indicator
Green
Power Supply
USB 5V
Color
Black
Max. Input Current
400mA
Max. Power Consumption
2W
Dimension
109.5mm*66mm*52.7mm (4.31"*2.59"*2.07")
Net Weight
111g (0.24lb)
Box Dimension
115mm*65mm*75mm (4.52"*2.55"*2.95")
Box Weight (with 1 product)
143g (0.31lb)
Protective Box Dimension
407mm*369mm*361mm (16.02"*14.52"*14.21")
Packaging Method
75 in 1
Operating Temperature
0°~+40° (+32?~+104?)
Operating Humidity
< 95% (Noncondensing)
Continuous Operating Time
? 72h of continuous normal operation
Storage Temperature
-20°~+60° (-4?~+140?)
Storage Humidity
< 95% (Noncondensing)
System Requirements
OS
Windows® 7 , Windows 8.1, Windows 10 or Higher
macOS™ 10.10 or Higher
Google™ Chromebook™ Version 29.0.1547.70 or Higher
Linux (UVC Protocol Required)
Certifications
Certifications
CE(EMC): EN 55032:2015+A11:2020, Class B; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE(LVD): EN 62368-1:2014+A11:2017; IEC 62368-1:2014 (Second Edition)
FCC: 47 CFR FCC Part15, Subpart B, Class B
